Stencils BGA Template 27Pcs/16Pcs/10Pcs Universal Direct Heated For SMT SMD Chip Repair

Azabooti presents the Stencils BGA Template set, a universal direct heat solution for SMT repairs. These templates help accurate rework and reduce solder waste across notebooks, desktops, and game consoles.

Precision BGA General Template – Universal Direct Heat Stencil Set

Achieve clean, professional rework of BGA chips with a universal direct heat stencil set that fits a wide range of devices. You get reliable templates designed to support your soldering project, reduce solder ball waste, and deliver consistent results when you repair notebooks, desktops, game consoles, and other graphic-related boards.

What you get

• Multi-piece assortments – available in 10, 16, or 27 piece configurations to cover diverse BGA footprints and chip sizes.
• Durable material – crafted from high‑quality nickel‑chrome alloy steel for enduring shape and heat resistance.
• Direct heat compatibility – stencils are designed for use with hot air rework gear; they tolerate heat without easy deformation when used correctly.
• Precise alignment and reduced waste – the stencil mesh area aligns with the BGA chip area to minimize solder ball loss and improve transfer accuracy.
• Wide footprint range – the set includes a broad mix of stencil sizes and pitches to match common BGA footprints across laptops, desktops, and graphics boards.
• Practical size options – example options include a variety of pitches and chip areas such as 0.3 to 0.76 universal stencils with pitches ranging from about 0.58 mm to 1.27 mm, plus larger 41 mm scale templates for diverse applications.
• Care and usage – works best with normal tin content and a controlled heat approach. Use a moderate air gun temperature to avoid deformation and preserve stencil integrity.

Specifications and compatibility

• Brand: NONE
• Model: BGA general template
• Type: Hand Tool Parts
• Material: Nickel-Chrome Alloy Steel
• Origin: Mainland China
• Use: Home DIY
• Estimated delivery days: 7
• Source Product ID: 1005002643419396
• Source Category ID: 142001

Whether you are performing a precise reball or rework, this universal stencil set is built to support accurate solder transfer and stable results. Follow standard safety practices when using hot air and ensure you are working in a well-ventilated area. The templates are sized to cover a broad spectrum of BGA footprints, so you can approach repairs with confidence and repeatable outcomes.

Features

• Improve transfer accuracy with precise alignment
• Reduce solder ball waste during rework
• Universal footprint coverage for varied BGA sizes
• Durable nickel chrome alloy construction
• Direct heat compatible for hot air rework
• Multi piece options 10 16 or 27
• Maintain stencil integrity under heat stress

Frequently Asked Questions

What projects can the BGA template set support?

The set supports rework on notebooks desktops game consoles and other graphic-related boards. It covers diverse BGA footprints to fit multiple devices.

How does direct heat compatibility benefit tapping BGA chips?

Direct heat compatibility ensures stable stencil performance under hot air rework. It minimizes deformation and improves solder transfer accuracy.
